Carbon Steel Fastener


Conceal Fixing









Wafer Head, Phillips Recess Self-Drilling Fastener.

Application :

Conceal fixing of metal clip system to medium steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1547-016-00-33

FC3 WFR #10-16x16mm

4.5mm

#2 Phillips

1547-022-00-33

FC3 WFR #10-16x22mm

4.5mm

#2 Phillips

1547-025-00-33

FC3 WFR #10-16x25mm

4.5mm

#2 Phillips

1547-032-00-33

FC3 WFR #10-16x32mm

4.5mm

#2 Phillips

1547-038-00-33

FC3 WFR #10-16x38mm

4.5mm

#2 Phillips

1547-050-00-33

FC3 WFR #10-16x50mm

4.5mm

#2 Phillips




Application – Crest Fixing









Hex Washer Flange, Double Threaded Self-Drilling Fastener with grey EPDM Washer.

Application :

Crest fixing of profiled roofing and cladding sheets to medium steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1530-045-50-33

FC3 HWF #12-14x45mm TT

6mm

8mm Hex

1530-050-50-33

FC3 HWF #12-14x50mm TT

6mm

8mm Hex

1530-055-50-33

FC3 HWF #12-14x55mm TT

6mm

8mm Hex

1530-060-50-33

FC3 HWF #12-14x60mm TT

6mm

8mm Hex

1530-065-50-33

FC3 HWF #12-14x65mm TT

6mm

8mm Hex

1530-070-50-33

FC3 HWF #12-14x70mm TT

6mm

8mm Hex

1530-075-50-33

FC3 HWF #12-14x75mm TT

6mm

8mm Hex

1530-080-50-33

FC3 HWF #12-14x80mm TT

6mm

8mm Hex

1530-090-50-33

FC3 HWF #12-14x90mm TT

6mm

8mm Hex

1530-100-50-33

FC3 HWF #12-14x100mm TT

6mm

8mm Hex

1530-125-50-33

FC3 HWF #12-14x125mm TT

6mm

8mm Hex

1530-150-50-33

FC3 HWF #12-14x150mm TT

6mm

8mm Hex

1530-175-50-33

FC3 HWF #12-14x175mm TT

6mm

8mm Hex

1530-200-50-33

FC3 HWF #12-14x200mm TT

6mm

8mm Hex

017-180-49-22

SBM HWH #14-14x250mm T3

6mm

8mm Hex




Application – Valley Fixing







































Hex Washer Flange, Self-Drilling Fastener with Grey EPDM Washer.

Application :

*Valley fixing of profiled roofing and cladding sheets to medium steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1524-016-50-33

FC3 HWF #10-16x16mm

4.5mm

8mm Hex

1524-020-50-33

FC3 HWF #10-16x20mm

4.5mm

8mm Hex

1524-025-50-33

FC3 HWF #10-16x16mm

4.5mm

8mm Hex

1529-020-50-33

FC3 HWF #12-14x20mm

6mm

8mm Hex

1529-025-50-33

FC3 HWF #12-14x25mm

6mm

8mm Hex

1529-030-50-33

FC3 HWF #12-14x30mm

6mm

8mm Hex

1529-035-50-33

FC3 HWF #12-14x35mm

6mm

8mm Hex

1529-040-50-33

FC3 HWF #12-14x40mm

6mm

8mm Hex

1529-045-50-33

FC3 HWF #12-14x45mm

6mm

8mm Hex

1529-050-50-33

FC3 HWF #12-14x50mm

6mm

8mm Hex

1529-060-50-33

FC3 HWF #12-14x60mm

6mm

8mm Hex

1529-065-50-33

FC3 HWF #12-14x65mm

6mm

8mm Hex

1529-070-50-33

FC3 HWF #12-14x70mm

6mm

8mm Hex

1529-080-50-33

FC3 HWF #12-14x80mm

6mm

8mm Hex

1529-100-50-333

FC3 HWF #12-14x100mm

6mm

8mm Hex

Hex Washer Head, Self-Drilling Fastener with OD19mm Steel Bonded Grey EPDM Washer.

Application :

Valley fixing of profiled roofing and cladding sheets to medium steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1515-020-29-33

FC3 HWH #14-14x20mm

6mm

10mm Hex

1515-025-29-33

FC3 HWH #14-14x25mm

6mm

10mm Hex

1515-020-29-33

FC3 HWH #14-14x30mm

6mm

10mm Hex

1515-040-29-33

FC3 HWH #14-14x40mm

6mm

10mm Hex

1515-060-29-33

FC3 HWH #14-14x60mm

6mm

10mm Hex

1515-080-29-33

FC3 HWH #14-14x80mm

6mm

10mm Hex

1515-100-29-33

FC3 HWH #14-14x100mm

6mm

10mm Hex

1515-0120-29-33

FC3 HWH #14-14x120mm

6mm

10mm Hex

1515-130-29-33

FC3 HWH #14-14x130mm

6mm

10mm Hex

1515-0150-29-33

FC3 HWH #14-14x150mm

6mm

10mm Hex

1515-175-29-33

FC3 HWH #14-14x175mm

6mm

10mm Hex

1515-200-29-33

FC3 HWH #14-14x200mm

6mm

10mm Hex

1515-225-29-33

FC3 HWH #14-14x225mm

6mm

10mm Hex




Application – Stitching




Hex Washer Flange, Stitching Fastener with EPDM Washer.

Application :

Specially designed for the fixing flashing and side laps.

Article number

Sizes

Drilling Capacity

Drive System

1551-020-50-33

FC3 HWF #10-16x20mm DN

1.5mm or 0.75mm x 2

8mm Hex

1551-020-50-33

FC3 HWF #14-14x22mm DR

2.00mm or 1.0mm x 2

8mm Hex




Carbon Thick Steel Application















Wafer Head, D5 Drill Point, Self-Drilling Fastener.

Application :

*Conceal fixing of metal clip system to hot rolled-steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1549-032-00-33

FC3 WFR #12-24x32mm D5

10.5mm

#3 Phillipsx

1549-038-00-33

FC3 WFR #12-24x38mm D5

10.5mm

#3 Phillips

1549-045-00-33

FC3 WFR #12-24x45mm D5

10.5mm

#3 Phillips

1549-055-00-33

FC3 WFR #12-24x55mm D5

10.5mm

#3 Phillips

109-032-49-22

SBM HWH #12-24x100mm D5

12.5mm

8mm Hex

Hex Washer Head, D5 Drill Point, Self-Drilling Fastener with OD16mm Aluminium Bonded EPDM Washer.

Application :

Valley fixing fixing of profiled roofing and cladding sheets to hot-rolled steel sections.

Article number

Sizes

Drilling Capacity

Drive System

1533-065-16-33

FC3 HWH #12-24x65mm D5

12.5mm

8mm Hex

1533-075-16-33

FC3 HWH #12-24x75mm D5

12.5mm

8mm Hex

1533-085-16-33

FC3 HWH #12-24x85mm D5

12.5mm

8mm Hex

1533-095-16-33

FC3 HWH #12-24x95mm D5

12.5mm

8mm Hex

1533-110-16-33

FC3 HWH #12-24x110mm D5

12.5mm

8mm Hex

1533-130-16-33

FC3 HWH #12-24x130mm D5

12.5mm

8mm Hex

1533-150-16-33

FC3 HWH #12-24x150mm D5

12.5mm

8mm Hex

1533-170-16-33

FC3 HWH #12-24x170mm D5

12.5mm

8mm Hex

1533-190-16-33

FC3 HWH #12-24x190mm D5

12.5mm

8mm Hex

1533-210-16-33

FC3 HWH #12-24x210mm D5

12.5mm

8mm Hex




Timber Purlin Application















Hex Washer Flange, Timber Self-Drilling Fastener with Grey EPDM Washer.

Application :

Valley fixing of profiled roofing and cladding sheets to timber sections.

Article number

Sizes

Drilling Capacity

Drive System

1535-025-50-33

FC3 HWF #12-11x25mm DT

20mm

8mm Hex

1535-035-50-33

FC3 HWF #12-11x35mm DT

30mm

8mm Hex

1535-025-50-33

FC3 HWF #12-11x25mm DT

30mm

8mm Hex

Hex Washer Flange, Double Threaded, Timber Self-Drilling Fastener with grey EPDM Washer.

Application :

Application :Crest fixing of profiled roofing and cladding sheets to Timber Sections.

Article number

Sizes

Drilling Capacity

Drive System

1536-060-50-33

FC3 HWF #12-11x60mm TTDT

30mm

8mm Hex

1536-080-50-33

FC3 HWF #12-11x80mm TTDT

30mm

8mm Hex

1536-110-50-33

FC3 HWF #12-11x100mm TTDT

30mm

8mm Hex

1536-125-50-33

FC3 HWF #12-11x125mm TTDT

30mm

8mm Hex

1536-150-50-33

FC3 HWF #12-11x150mm TTDT

30mm

8mm Hex

1536-175-50-33

FC3 HWF #12-11x175mm TTDT

30mm

8mm Hex
